Intel Core i7 12700 12 Core Processor, 20 Threads, 2.1GHz up to 4.9GHz Turbo Alder Lake Socket LGA 1700 25MB Cache, 65W, Maximum Turbo Power 180W, Intel UHD 730 Graphic

• Socket: 1700
• On-Chip Graphics: Yes
• Speed: 2.1GHz
• Core Quantity: 12
• Prefix: Core i7

Chip Name
BX8071512700
Alder Lake

Socket
LGA1700

Total Cores
12

Number of Peformance Cores
8

Number of Efficient Cores
4

Total Threads
20

Max Turbo Frequency
4.90Ghz

Intel Turbo Boost Max Technology 3.0 Frequency
4.9Ghz

Performance-core Max Turbo Frequency
4.80Ghz

Efficient-core Max Turbo Frequency
3.60Ghz

Performance-core Base Frequency
2.1Ghz

Efficient-core Base Frequency
1.6Ghz

Cache
25MB

Total L2 Cache
12MB

Processor Base Power
65W

Maximum Turbo Power
180W

Max Memory Size (dependent on memory type)
128GB

Processor Graphics
Intel UHD Graphics 770

Graphics Base Frequency
300 MHz

Graphics Max Dynamic Frequency
1.50 GHz

Graphics Output
eDP 1.4b, DP 1.4a, HDMI 2.1

Execution Units
32

Max Resolution (HDMI)
4096 x 2160 @ 60Hz

Max Resolution (DP)
7680 x 4320 @ 60Hz

DirectX Support
12

OpenGL Support
4.5

Intel Quick Sync Video
Yes

Intel Clear Video HD Technology
Yes

Number of Displays Supported
4

OpenCL Support
2.1

Direct Media Interface (DMI) Revision
4.0

PCI Express Revision
5.0 and 4.0

Max Number of PCI Express Lanes
20

Heatsink
Y

Packaging
Retail
Y
