Mercusys MB115-4G N300 Wi-Fi 4G LTE Router

• Connection Type: 3G/4G
• Wireless Standard: 300Mbps

Mercusys MB115-4G 300 Mbps Wireless N 4G LTE Router

4G network
Share internet access with up to 32 Wi-Fi devices and enjoy download speeds of up to 150 Mbps

Plug a SIM card and play
No configurations needed, compatibility of SIM cards are assured by years of field tests

300 Mbps WiFi
Fast WiFi speeds up to 300 Mbps to share your network

Maximum Network Coverage
Enjoy stable and efficient connections to every device thanks to the four external antennas
Wi-Fi router mode – Plug an Ethernet cable into the LAN/WAN port for flexible access if you can’t get a 4G connection
*Notes: Make sure your SIM card is unlocked.

WirelessWireless Standards
IEEE 802.11b/g/n

Frequency
2.4 GHz

Signal Rate
300 Mbps

Reception Sensitivity
11g 54M: -74.5 dBm
11n HT20 MCS7: -73.5 dBm
11n HT40 MCS7: -70.5 dBm

Transmission Power
< 20 dBm (2.4 GHz) Wireless

Security
WPA-PSK / WPA2-PSK

Wireless Functions
Enable/Disable Wireless Radio, Wireless Schedule, WMM, Wireless
Statistics

Software

DHCP
Server

Hardware

Dimensions (W X D X H)
219 x 140 x 32 mm
(8.62 x 5.51 x 1.26 in)

Interfaces
1x 10/100Mbps LAN/WAN Port
3x 10/100Mbps LAN Ports
1x Nano SIM Card Slot

Button
WPS
Reset Button

Ethernet Ports
1x 10/100 Mbps LAN/WAN Port
3x 10/100 Mbps LAN Ports

Network Type
EU:
FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700 MHz)
TDD-LTE: B38/B40 (2600/2300 MHz)
HSPA+/UMTS: B1/B5/B8 (2100/850/900 MHz)

Others

Package Contents
300 Mbps Wireless N 4G LTE Router (MB115-4G)
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide

Environment
Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~60°C (-40°F~140°F)

Operating Humidity: 10%~90% Non-Condensing

Storage Humidity: 5%~90% Non-Condensing
